Gear Pump (HGP-3AI)

Displacement: 2~ 35 c.c. / rev.

Maximum Pressure: 280 kg/cm2 (3920 psi)

Flange: SAE 2-bolt, DIN 4-bolt

Contact
Back
add to Inquiry Cart Model Mounting Delivery Capacity Rotation Direction Shaft Type Flange Mounting Type Inlet and Outlet

HGP-3AI-2

 F: Flange / L: Foot 2 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-3

 F: Flange / L: Foot 3 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-4

 F: Flange / L: Foot 4 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-6

 F: Flange / L: Foot 6 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-8

 F: Flange / L: Foot 8.4 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-11

 F: Flange / L: Foot 11 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-13

 F: Flange / L: Foot 13 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-14

 F: Flange / L: Foot 14.3 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-17

 F: Flange / L: Foot 16.5 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-19

 F: Flange / L: Foot 19.2 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-23

 F: Flange / L: Foot 23 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-25

 F: Flange / L: Foot 25 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-28

 F: Flange / L: Foot 28 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-30

 F: Flange / L: Foot 30 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-33

 F: Flange / L: Foot 33 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)

HGP-3AI-35

 F: Flange / L: Foot 35 R: Clockwise / L: Counter-Clockwise X: Straight / Y: Spline / Z: Taper 2B : SAE 2-bolt / 4BD : DIN 4-bolt F: Flange (F1~F6) / G: G, BSP, PF (G1~G2) / P: PT (P1~P2) / U: UNF (U1~U3)
